Unlimited Board UB603 V2
#5682
New
Unlimited Board UB603 V2, светодиоды Seoul Semiconductor. Борд содержит всего 568шт полупроводниковых кристаллов. Модуль оснащается разъемами для подключения цангового типа, а так же имеет два режима работы "цветение" и "вегетация".
Data sheet
| Installed LEDs: | Seoul Semiconductor SMD |
| Wavelength/Color Temperature: | 3500K |
| Illumination Color: | Warm white |
| Color Rendering Index - CRI: | 3400K Ra88+ |
| Viewing Angle: | 115° |
| If - Forward Current: | 3000mA |
| Maximum drive current: | 7000mA |
| Vf - Forward Voltage: | 49-54V |
| Power Rating: | 51W@1050mA, 70W@1400mA, 107W@2100MA, 160W @3000mA, 250W@4500mA |
| The size: | 285x175mm |
More info
The Unlimited Board UB603 V2 LED panel can be used without a radiator with an operating mode of no more than 50W. However, to maximize the efficiency and life of the LEDs, we recommend installing the QB on a heatsink under all conditions.
Unlimited Board UB603 V2 is a new module in the LED market. Has two modes of operation, simple switching, does not require additional power supplies. Supports standard dimming. In comparison with classic boards on the Samsung LM301H, it has a power reserve of 100W.
